5KW Belt Power System For BJ80 ※ Sicote Generator Set Markt

Wuxi Sicote Power Technology CO., Ltd. produce 5KW Belt Power System For BJ80；

5KW Belt Power System For BJ80 Tech Data

◆ Tech Data Of SICOTE Belt Alternator			{ Need 1 belt alternator in this system } Idle Power : 5.0KW			{ Product Model：S4CT5000-BJ80-3.0T }
Alternator Model	Single Belt Alternator Tech Data						Control Model
S4C5000PLD	Engine Speed	750 RPM { when parking }	1000 RPM	1300 RPM	1600 RPM	2000 RPM { when driving }	S4C5000-4U-230
Alternator Voltage	Output Current	90A	97A	100A	105A	108A	Controler Style
DC 56 V	Output Power	5.0KW { Idle Power }	5.4KW	5.6KW	5.9KW	6.0KW { Max Power }	4U Standard Cabinet
working temperature : -40℃ — +100℃; storage temperature : -40℃ — +70℃; relative humidity : 95±3% (at +40℃) Cooling Method Of Belt Alternator ：Air-cooled
Meet the standard：GJB150.9A-2009 , GJB150.10A-2009 , GJB150.11A-2009 , GJB150.16A-2009

◆ Electrical Data Of Belt Power System※ Adequate idle power, no need to accelerate ※ { AC Voltage: 220/230/240Can Change }
AC Voltage	Frequency	AC Voltage stability time	Frequency stability time	AC input		Automatic switching	Manual switching	Intelligent charging	Speed Device	Remote Control	UPS			Power battery Data		Single Power battery Size
AC Voltage	Frequency	AC Voltage stability time	Frequency stability time	Interface	Protect	Automatic switching	Manual switching	Intelligent charging	Speed Device	Remote Control	Function	Charge	Warning	Capacity	QTY	L	W	H
230±2V	50±0.1HZ	≤1S	≤3S						NO	NO				38AH	4	197	165	170

◆ List Of SICOTE Belt Power System
SICOTE Belt Alternator		SICOTE Controler System		SANTAK CASTLE Power battery			Anti Reflux Device	DC Change Device	Bracket	Pulley	Tightening wheel QTY	Guiding wheel QTY	Bolt Nut	Speed Up Device	Power Cable	Belt
QTY	Total Weight	QTY	Total Weight	Capacity	QTY	Total Weight	Anti Reflux Device	DC Change Device	Bracket	Pulley	Tightening wheel QTY	Guiding wheel QTY	Bolt Nut	Speed Up Device	Power Cable	Belt
1 PCS	12.3Kg	1 PCS	40Kg	38AH	4	45.6Kg	0	0	1	1 PCS	1 PCS	2 PCS	1	0	1	2 PCS
[Other instructions]: Users can download the information by the vehicle number in our website

Get filter if the total money in your shopcat above stipulated amount
Activity Time : From2024-06-01 0:0 To 2025-05-31 0:0
Active Object : all people

Reduce Shipping Costs For Your Buying
Activity Time : From2023-12-20 0:0 To 2025-12-21 0:0
Active Object : all people

Purchase our products to meet the conditions of discount
Activity Time : From2024-06-01 0:0 To 2025-05-31 0:0
Active Object : all people

You can get a coupon in our website
Activity Time : From2023-01-01 0:0 To 2024-12-31 0:0
Active Object : all people

Less than truckload transportation (freight collect)
Need Time : 3-10 Days [ In China ]
Charging Method : Order billing (basic cost)
Basic Weight : Shipping by the buyer or the instructions under the contract
Free Scope : This distribution is No Free distribution
Logistics Scope : FOB shanghai

Large cargo loading (freight collect)
Need Time : 3-4 Days [ In China ]
Charging Method : Order billing (basic cost)
Basic Weight : Shipping by the buyer or the instructions under the contract
Free Scope : This distribution is No Free distribution
Logistics Scope : FOB shanghai

Special car express (freight collect)
Need Time : 2-3 Days [ In China ]
Charging Method : Order billing (basic cost)
Basic Weight : Shipping by the buyer or the instructions under the contract
Free Scope : This distribution is No Free distribution
Logistics Scope : FOB shanghai

Diesel generator set warranty repairs and claims provisions

A quality guarantee period
1. diesel generator set from the factory date twelve months or crew running 1000 hours, the end of one of these two time limits to achieve that quality assurance.
The contract otherwise special agreement subject to contract.
Second, the quality assurance of free maintenance range
User should be in accordance with the generator sets and ancillary components (including engine, generator) Use and maintenance manual requirements for normal use and maintenance, product quality assurance of failure by the service engineer or authorized personnel (including the supply vendor personnel permitted) test due to failure caused by quality defects or assembly of the product itself, I am responsible for free replacement parts or maintenance.
Does not belong to the scope of quality assurance during the free maintenance:
Transport their own installation and maintenance works damaged by direct person in charge of compensation.
2. to be demolished without the consent of the Company.
3. without the damage caused to the Company agreed to change the product without structure or unauthorized installation of other devices.
4. do not follow the product manual installation, maintenance requirements for installation, maintenance and damage.
5. Fails to product specification stipulates that the use of models and brands improper, can not guarantee the quality of lubricating oil.
6. Fails to use models, product specification provides brand properly, can not guarantee the quality antifreeze.
7. Fails to maintenance requirements, timing replace the oil filter, diesel filter, air filter.
8. unused product brochures under the oil filter, diesel filter, air filter.
Fourth, the responsibilities and obligations of the Company
The company commitment to quality assurance free maintenance during the period of direct costs, do not bear the resulting overheads and indirect losses.
Taking into account regional differences, our service response time in different parts of the contract in accordance with the development of different response time included in the contract areas.
Responsibilities and obligations of the corporate users
1 user is responsible for the use and maintenance in accordance with the requirements of the specification.
Save a true record of the use and maintenance of all operating, not fraud.
Assist service engineers or authorized personnel (including the supply vendor personnel permitted) check and determine the cause of the malfunction.
